SILENCED MODEL.jpg
SILENCED MODEL

This is a new series of Silenced EC mixed flow in-line fan, compact, and featured with super quiet performance.

The fan is built with Basic model inside and assembled with high density noise absorbing foam. Vibration free between fan and housing.





Main Features



Rotatable spring anti-vibration design

High density sound foam.

Easier Duct Connection Design with Detachable Bracket


Blade Fire Proofing Grade UL94V-0


Detachable 0%-100% Speed Control(potentiometer) Included /

Concealed Switch (Optional)


6-Poles Brushless Motor with Sine Wave


Double Heavy Duty NMB Ball Bearing


Locked Rotor Protection [AUTO-RESTART]; Soft-Start Motor;

Over-Voltage Lockout Protection


Customized Feature: PWM/Control by 0-10v/Voltage output/Tacho Output


Max. IP68 Water-proof Level Available




BLDC motor is more durable. It retains its high performance while the efficiency and power of an equivalent conventional motor declines due to wear, causing poor brush contact, arcing between the brushes and the commutator dissipating energy, and dirt compromising electrical conductivity.

HIGH EFFICIENT EC MOTOR DRIVE


sensdar offers one-stop thermal solution service that includes the manufacture of various cooling modules and thermal configurations, all varieties. Complimentary design services are available for developing optimal thermal structure depending on system applications in order to satisfy clients’ thermal needs and also to achieve the highest thermal efficiency.all varieties. Complimentary design services are available for developing optimal thermal structure depending on system applications in order to satisfy clients’ thermal needs and also to achieve the highest thermal efficiency.

QUIET OPERATION

Printed Circuit Board: Independent research and development, exclusive control program, support single-voltage and dual-voltage multi-specification parameters, and support to change to DC power supply, adapt to a variety of control signals. Contains automatic lock, soft start, overload protection and high temperature protection functions

QUIET OPERATION


sensdar offers one-stop thermal solution service that includes the manufacture of various cooling modules and thermal configurations, all varieties. Complimentary design services are available for developing optimal thermal structure depending on system applications in order to satisfy clients’ thermal needs and also to achieve the highest thermal efficiency.all varieties. Complimentary design services are available for developing optimal thermal structure depending on system applications in order to satisfy clients’ thermal needs and also to achieve the highest thermal efficiency.

OPTIONAL CONTROLS & ACCESSORY

SENSDAR EC fan offers great flexibility and compatibility of speed control with various accessory: smart control, remote control, wall mounted variable control, controller adaptors and extension cable.

Improved Verison with Easier Duct Connection & Detachable Bracket  Available Sizes: 6" / 8" / 10" /12"

FAN SPECIFICATION
